Symbols and programmes on your Zanussi dishwasher

Resolution

Your Zanussi dishwasher is equipped with useful indicators, programmes and options.

Different Zanussi dishwashers may have varying indicators, programmes and options. Check the user manual for details on your dishwasher model.

Indicators

	Salt indicator The salt container needs refilling. It is always off while a programme operates.
	Rinse aid indicator The rinse aid dispenser needs refilling. It remains off while a programme is running.
	Cleaning phase indicator The cleaning phase is running.
	Rinsing phase indicator The rinsing phase is running.
	Drying phase indicator The programme includes a drying phase. It flashes when the drying phase is running.

Programmes

Depending on your model, you have a selection of different programmes to choose from.

Different Zanussi dishwashers may have varying indicators, programmes and options. Check the user manual for details on your dishwasher model.

	Pre-wash (Pre-Rinse) Quick rinse to clean food residue and prevent odours if you’re not immediately starting a programme. Do not use detergent.
	ECO The longest programme offering the most efficient use of energy and water consumption. Works for dishes, cutlery and cookware with normal and slightly dry residue. The cycle will take longer than standard programmes.
	AUTO Automatic, tailored settings with sensors that determine how dirty the dishes are and the amount of dishes in the baskets. Works for dishes, cutlery and cookware with normal and slightly dry residue.
	30 minutes Short programme for slightly dirty dishes and cutlery. Dishes will not be dried.
	60 minutes Programme for slightly dirty dishes and cutlery you've just used. Also works for lightly dried-on residue.
	90 minutes Optimal for dishes and cookware with an average amount of fresh and dry residue.
	160 minutes Longer programme optimal for dishes, cutlery and cookware with a normal to heavy amount of residue, or with dried-on residue.

Options

Choose among optional add-ons after you’ve selected programme or set programme duration. Depending on your model, you may have one or several options to choose from. Some options affect water and energy consumption as well as programme length.

EXTRA POWER	ExtraPower This option improves the washing results of the selected programme. It increases the wash temperature and duration.
AIRDRY	AIRDRY AirDry improves the drying results. The appliance door opens automatically during the drying phase and remains ajar. AirDry is automatically activated with all programmes other than Pre-rinse.
END SOUND	END SOUND You can activate an acoustic signal that sounds when the programme is completed. Acoustic signals sound also when a malfunction of the appliance occurs. It is not possible to deactivate these signals.
KEY TONES	KEY TONES The buttons on the control panel make a click sound when you press them. You can deactivate this sound.

Delay start

Delay start
Delays the start of the selected dishwashing cycle.

How to use it
1. Set a programme
2. Press Delay repeatedly until the display shows the desired delay time (from 1 to 24 hours, depending on model)
3. Press Start to begin the countdown. The indicator is on during the countdown

Maintenance

Machine Care

Cleans the inside of the dishwasher, removing limescale and grease build-up.

Recommended use

Run at least once every two months with a descaler or a cleaning product designed for dishwashers. Run without any load.
